Viscous Coupling of Lamborghini Lamborghini Diablo VT Roadster (1998-2000)

Lamborghini Diablo VT Roadster (1998-2000) - Viscous Coupling

부품 분해도를 보고 원하는 부품을 찾으세요.:

다이어그램을 드래그하여 위치를 변경할 수 있습니다.
다이어그램을 스크롤하거나 핀치하거나 and buttons

부품 다이어그램에서 핫스팟 클릭하여 표에서 부품을 찾을 수 있습니다.

부품 키

재고 있음

곧 도착

주문하기

문의하세요

다이어그램 탭하여 확대

0 부품 ($0.00)

경고: 항목에 대해 동일한 부품의 여러 이형 상품을 선택할 수 있습니다:

	#	부품 번호	부품 설명	부품 세부 정보	가격 (각)	수량 다이어그램	키
	8525013		BEARING	from $305.58
001 BEARING $305.58 1 TO 034 BEARING $305.58 1 TO
	8589001		RETAINER RING	from $3.40 MSRP: ~~3.55~~ (4.2% off)
002 RETAINER RING $3.40 MSRP: ~~3.55~~ (4.2% off) 1 TO 035 RETAINER RING $3.40 MSRP: ~~3.55~~ (4.2% off) 1 TO
	003	2437703	VISCOUS COUPLING	2437703 VISCOUS COUPLING (Valid for 4WD only) GIUNTO VISCOSO	$11,811.99	1	TO
	004	24001008	GEAR	24001008 GEAR (Valid for 4WD only) INGRANAGGIO	$1,018.99	1	TO
	005	2437409	PLUG	2437409 PLUG (Valid for 4WD only) GHIERA	$204.58	1	TO
	8578001		RETAINER RING	from $6.55
006 RETAINER RING $6.55 1 TO 037 RETAINER RING $6.55 1 TO
	8514001		BEARING	from $144.63 MSRP: ~~152.00~~ (4.8% off)
007 BEARING $144.63 MSRP: ~~152.00~~ (4.8% off) 1 TO 038 BEARING $144.63 MSRP: ~~152.00~~ (4.8% off) 1 TO
	8254004		PLUG	from $139.43 MSRP: ~~147.50~~ (5.5% off)
008 PLUG $139.43 MSRP: ~~147.50~~ (5.5% off) 1 TO 039 PLUG $139.43 MSRP: ~~147.50~~ (5.5% off) 1 TO
	8575201		RETAINING RING	from $2.09 MSRP: ~~7.20~~ (71% off)
009 RETAINING RING IN $2.09 MSRP: ~~7.20~~ (71% off) 4 IN 040 RETAINING RING IN $2.09 MSRP: ~~7.20~~ (71% off) 1 IN
	86311819		SEAL RING	from $56.87
010 SEAL RING IN $56.87 1 IN 041 SEAL RING IN $56.87 1 IN
	011	8605002	SEAL	8605002 SEAL (Valid for 4WD only) ANELLO TENUTA	$1.67 MSRP: ~~7.25~~ (77% off)	1	TO
	012	2436927	COVER	2436927 COVER (Valid for 4WD only) COPERCHIO	$205.22 MSRP: ~~209.50~~ (2% off)	1	TO
	013	8252502	PLUG	8252502 PLUG (Valid for 4WD only) GHIERA	$157.02	1	TO
	014	8512500	BEARING	8512500 BEARING (Valid for 4WD only) CUSCINETTO	$138.13 MSRP: ~~146.00~~ (5.4% off)	1	TO
	015	2430936	SPACER	2430936 SPACER (Valid for 4WD only) DISTANZIALE	$65.68 MSRP: ~~66.90~~ (1.8% off)	1	TO
	016	8523517	ROLLER CAGE	8523517 ROLLER CAGE (Valid for 4WD only) CUSCINETTO	$22.65	1	TO
	017	2431869	SMALL SHAFT	2431869 SMALL SHAFT (Valid for 4WD only) ALBERINO	$5,503.18	1	TO
	018	2433672	GEAR	2433672 GEAR (Valid for 4WD only )INGRANAGGIO	$2,204.31	1	TO
	019	8582501	RETAINER RING	8582501 RETAINER RING (Valid for 4WD only) ANELLO RITEGNO	$5.75 MSRP: ~~6.00~~ (4.2% off)	1	TO
	020	8522509	BEARING	8522509 BEARING (Valid for 4WD only) CUSCINETTO	$194.58	1	TO
	021	8576601	RETAINER RING	8576601 RETAINER RING (Valid for 4WD only) ANELLO RITEGNO	$0.66 MSRP: ~~7.26~~ (90.9% off)	2	TO
	022	8253005	PLUG	8253005 PLUG (Valid for 4WD only) GHIERA	$19.10 MSRP: ~~20.20~~ (5.4% off)	1	TO
	023	2433673	GEAR	2433673 GEAR (Valid for 4WD only) INGRANAGGIO	$1,907.88	1	TO
	024	8577601	RETAINER RING	8577601 RETAINER RING (Valid for 4WD only) ANELLO RITEGNO	$3.28 MSRP: ~~3.40~~ (3.5% off)	1	TO
	025	8523516	BEARING	8523516 BEARING (Valid for 4WD only) CUSCINETTO	$66.13	1	TO
	026	2434628	PROPELLER SHAFT	2434628 PROPELLER SHAFT (Valid for 4WD only) ALBERO TRASMISSIONE	$618.95 MSRP: ~~632.00~~ (2.1% off)	1	TO
	027	8513000	BEARING	8513000 BEARING (Valid for 4WD only) CUSCINETTO	$76.50 MSRP: ~~80.90~~ (5.4% off)	1	TO
	028	8606502	SEAL	8606502 SEAL (Valid for 4WD only) ANELLO TENUTA	$0.56 MSRP: ~~7.29~~ (92.3% off)	1	TO
	029	2434637	FLANGE	2434637 FLANGE (Valid for 4WD only) FLANGIA	$344.00 MSRP: ~~350.00~~ (1.7% off)	1	TO
	030	8614211	SEAL	8614211 SEAL (Valid for 4WD only) ANELLO TENUTA	$22.75	1	TO
	031	8575501	RETAINING RING	8575501 RETAINING RING (Valid for 4WD only) ANELLO RITEGNO	$1.26 MSRP: ~~7.13~~ (82.3% off)	1	TO
	032	2434627	FLANGE	2434627 FLANGE (Valid for 4WD only) FLANGIA	$1,085.44 MSRP: ~~1,150.00~~ (5.6% off)	1	TO
	033	8252505	PLUG	8252505 PLUG (Valid for 4WD only) GHIERA	$87.27	1	TO
	036	2437437	RING GEAR	2437437 RING GEAR (Can be used as a gear transmission end) CORONA DENTATA	$989.01	1	TO
