Driven Shaft Gears of Lamborghini Lamborghini Diablo SV (1995-1997)

Lamborghini Diablo SV (1995-1997) - Driven Shaft Gears

부품 분해도를 보고 원하는 부품을 찾으세요.:

다이어그램을 드래그하여 위치를 변경할 수 있습니다.
다이어그램을 스크롤하거나 핀치하거나 and buttons

부품 다이어그램에서 핫스팟 클릭하여 표에서 부품을 찾을 수 있습니다.

부품 키

재고 있음

곧 도착

주문하기

문의하세요

다이어그램 탭하여 확대

0 부품 ($0.00)

경고: 항목에 대해 동일한 부품의 여러 이형 상품을 선택할 수 있습니다:

#	부품 번호	부품 설명	부품 세부 정보	가격 (각)	수량 다이어그램	키
001	2424886	GEAR	2424886 GEAR INGRANAGGIO 1 - MARCIA	$1,954.57 MSRP: ~~2,060.00~~ (5.1% off)	1	TO
002	8524701	ROLLER CAGE	8524701 ROLLER CAGE GABBIAARULLI	$47.30 MSRP: ~~50.10~~ (5.6% off)	4	TO
003	2420124	SPLINED BUSHING	2420124 SPLINED BUSHING BOCCOLA DENTATA	$503.20	4	TO
004	2424864	WASHER	2424864 WASHER RONDELLA	$186.24	4	TO
005	2421416	FRICTION RING	2421416 FRICTION RING ANELLO FRENANTE	$1,505.00	4	TO
006	2425150	SLEEVE T/OBEARING	2425150 SLEEVE T/OBEARING MANICOTTO DISINNESTO	$1,368.21 MSRP: ~~1,395.00~~ (1.9% off)	2	TO
007	2421680	SYNCHRONIZER	2421680 SYNCHRONIZER CORPO SINCRONIZZATORE	$319.91 MSRP: ~~326.00~~ (1.9% off)	2	TO
008	2424891	GEAR	2424891 GEAR INGRANAGGIO R.M.	$441.74 MSRP: ~~451.00~~ (2.1% off)	1	TO
009	2424860	SHIM	2424860 SHIM DISTANZIALE	$127.05 MSRP: ~~129.50~~ (1.9% off)	1	TO
010	8576201	RETAINER RING	8576201 RETAINER RING ANELLO RITEGNO	$2.95 MSRP: ~~3.00~~ (1.7% off)	2	TO
011	8524011	BEARING	8524011 BEARING CUSCINETTO	$147.02	1	TO
012	2437436	COUNTERSHAFT	2437436 COUNTERSHAFT ALBERO SECONDARIO	$3,381.38 MSRP: ~~3,445.00~~ (1.8% off)	1	TO
013	8576601	RETAINER RING	8576601 RETAINER RING ANELLO RITEGNO	$0.66 MSRP: ~~7.26~~ (90.9% off)	1	TO
014	8523009	BEARING	8523009 BEARING CUSCINETTO	$66.53	1	TO
015	8583001	RETAINER RING	8583001 RETAINER RING ANELLO RITEGNO	$0.50 MSRP: ~~7.30~~ (93.2% off)	1	TO
016	2421418	SPRING	2421418 SPRING MOLLA	$66.88	6	TO
017	2421420	BRAKE PAD	2421420 BRAKE PAD PATTING	$29.35	6	TO
018	2421419	PIN	2421419 PIN PERNO	$34.42	6	TO
019	2424862	WASHER	2424862 WASHER RONDELLA	$226.09 MSRP: ~~230.50~~ (1.9% off)	2	TO
020	8522008	ROLLER CAGE	8522008 ROLLER CAGE GABBIA A RULLI	$11.27 MSRP: ~~11.90~~ (5.3% off)	2	TO
021	2424869	GEAR	2424869 GEAR INGRANAGGIO R.M.	$240.40 MSRP: ~~245.50~~ (2.1% off)	1	TO
022	8700649	SCREW	8700649 SCREW VITE	$7.83 MSRP: ~~8.25~~ (5.1% off)	1	TO
023	2431824	NUT	2431824 NUT DADO	$95.40 MSRP: ~~97.30~~ (2% off)	1	TO
024	8503006	BEARING	8503006 BEARING CUSCINETTO	$560.31 MSRP: ~~593.00~~ (5.5% off)	1	TO
025	2426685	GEAR	2426685 GEAR INGRANAGGIO 5 - MARCIA	$736.23	1	TO
026	2424866	SPLINED BUSHING	2424866 SPLINED BUSHING BOCCOLA DENTATA	$240.21	1	TO
027	2424872	GEAR	2424872 GEAR INGRANAGGIO 4 - MARCIA	$789.64	1	TO
028	2424888	GEAR	2424888 GEAR INGRANAGGIO 3 - MARCIA	$1,726.52 MSRP: ~~1,820.00~~ (5.1% off)	1	TO
029	2427098	GEAR	2427098 GEAR INGRANAGGIO 2 - MARCIA	$1,702.64	1	TO
030	2424863	WASHER	2424863 WASHER RONDELLA	$98.12 MSRP: ~~100.50~~ (2.4% off)	1	TO
031	2424865	SMALL SHAFT	2424865 SMALL SHAFT ALBERINO	$114.48	1	TO
