| # | 부품 번호 |
부품 설명 |
부품 세부 정보 | 가격 (각) |
수량 다이어그램 |
주문하기 주문 수량 |
키 | 에 추가 장바구니 |
||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 001 | 8401006 | WASHER |
8401006 WASHER RONDELLA |
$0.61 MSRP: |
6 |
TO
|
||||||
| 002 | 4232621 | PIN |
4232621 PIN PERNO |
$37.23 MSRP: |
2 |
TO
|
||||||
| 003 | 4225060 | ROCKER |
4225060 ROCKER LEVA |
$74.42 MSRP: |
1 |
TO
|
||||||
| 004 | 8801209 | BUSHING |
8801209 BUSHING BOCCOLA |
$9.40 MSRP: |
1 |
TO
|
||||||
| 005 | 4225061 | COUPLING |
4225061 COUPLING TESTAASNODO |
$67.51 MSRP: |
1 |
TO
|
||||||
| 006 | 1321270 | SPRING |
1321270 SPRING MOLLA |
$8.28 | 2 |
TO
|
||||||
| 007 | 8802501 | BUSHING |
8802501 BUSHING BOCCOLA |
$21.62 MSRP: |
2 |
TO
|
||||||
| 008 | 4210834 | ADJUSTING SLEEVE |
4210834 ADJUSTING SLEEVE TESTA REGISTRO |
$4.46 MSRP: |
2 |
TO
|
||||||
| 009 | N01100637 | NUT M6 |
N01100637 NUT M6 DADO |
$0.34 MSRP: |
2 |
TO
|
||||||
| 010 | 8900803 | PIN |
8900803 PIN SA |
$0.95 MSRP: |
2 |
TO
|
||||||
| 011 | 4225064 | SHAFT |
4225064 SHAFT ALBERO |
- | 1 |
PE
|
문의하기 | |||||
| 012 | 8400819 | WASHER 8X12X1 |
8400819 WASHER 8X12X1 RONDELLA |
$0.60 MSRP: |
2 |
TO
|
||||||
| 013 | 8200801 | NUT M8 |
8200801 NUT M8 DADO |
$0.37 | 1 |
TO
|
||||||
| 014 | N0147519 | SCREW M8X50 |
N0147519 SCREW M8X50 VITE |
$12.70 | 1 |
TO
|
||||||
8200804 |
NUT M8 |
from
$1.98 MSRP: |
|
|||||||||
| 016 | 4238042 | LEVER |
4238042 LEVER LEVA |
$33.70 MSRP: |
1 |
TO
|
||||||
| 017 | 4230089 | GAS CABLE |
4230089 GAS CABLE TIRANTE ACCELERATORE |
$1,134.95 | 1 |
TO
|
||||||
| 019 | N0152785 | WASHER |
N0152785 WASHER RONDELLA |
$0.72 | 1 |
TO
|
||||||
| 020 | 8400801 | WASHER |
8400801 WASHER RONDELLA |
$0.66 | 1 |
TO
|
||||||
| 021 | 8401220 | WASHER |
8401220 WASHER RONDELLA |
$5.86 MSRP: |
2 |
TO
|
||||||
| 022 | 8521205 | BEARING |
8521205 BEARING CUSCINETTO |
$10.90 MSRP: |
2 |
TO
|
||||||
| 023 | 4231811 | SUPPORT - SUPPORTO |
4231811 SUPPORT - SUPPORTO O |
$248.23 MSRP: |
1 |
TO
|
||||||
| 024 | 8581101 | RETAINER RING |
8581101 RETAINER RING ANELLO RITEGNO |
$5.75 MSRP: |
1 |
TO
|
||||||
| 025 | 4230143 | GAS PEDAL |
4230143 GAS PEDAL PEDALE ACCELERATORE |
$540.76 MSRP: |
1 |
TO
|
||||||
| 026 | 4228351 | PEDAL PAD |
4228351 PEDAL PAD COPRIPEDALE GOMMA |
$73.66 | 1 |
TO
|
||||||
| 027 | 42001105 | BRAKE PEDAL |
42001105 BRAKE PEDAL PEDALE FRENO |
$385.68 MSRP: |
1 |
TO
|
||||||
| 028 | 4228349 | PEDAL PAD |
4228349 PEDAL PAD COPRIPEDALE GOMMA |
$46.69 | 1 |
TO
|
||||||
| 029 | 4235355 | CLUTCH PEDAL |
4235355 CLUTCH PEDAL PEDALE FRIZIONE |
$385.68 MSRP: |
1 |
TO
|
||||||
| 030 | 4232622 | PIN |
4232622 PIN PERNO |
$26.26 MSRP: |
1 |
TO
|
||||||
| 031 | 8581004 | CLIP |
8581004 CLIP MOLLETTA |
$9.18 MSRP: |
3 |
TO
|
||||||
| 032 | N10155210 | NUT |
N10155210 NUT DADO |
$1.98 MSRP: |
1 |
TO
|
||||||
| 033 | 4225062 | TIE ROD |
4225062 TIE ROD TIRANTE |
$64.76 MSRP: |
1 |
TO
|
||||||
| 034 | 8900305 | PIN - SPINA |
8900305 PIN - SPINA SA |
$0.27 MSRP: |
2 |
TO
|
||||||
| 035 | 4225074 | PIN |
4225074 PIN PERNO |
- | 1 |
PE
|
문의하기 | |||||
4236013 |
TIE ROD |
from
$153.12 MSRP: |
|
|||||||||
