Clutch (e-gear) of Lamborghini Lamborghini Murcielago LP670

Lamborghini Murcielago LP670 - Clutch (e-gear)

부품 분해도를 보고 원하는 부품을 찾으세요.:

다이어그램을 드래그하여 위치를 변경할 수 있습니다.
다이어그램을 스크롤하거나 핀치하거나 and buttons

부품 다이어그램에서 핫스팟 클릭하여 표에서 부품을 찾을 수 있습니다.

부품 키

재고 있음

곧 도착

주문하기

문의하세요

다이어그램 탭하여 확대

0 부품 ($0.00)

경고: 항목에 대해 동일한 부품의 여러 이형 상품을 선택할 수 있습니다:

#	부품 번호	부품 설명	부품 세부 정보	가격 (각)	수량 다이어그램	키	에 추가 장바구니
004	N1100845	NUT M8X1,25X6,5	N1100845 NUT M8X1,25X6,5	-	10	PE	문의하기
005	WHT000771	WASHER IN	WHT000771 WASHER IN	$2.03	16	IN
006	1J0615273	BREATHER VALVE	1J0615273 BREATHER VALVE	$23.15	1	TO
007	86301147	DUST CAP IN	86301147 DUST CAP IN	$1.55 MSRP: ~~7.25~~ (78.6% off)	1	IN
008	86323173C	CONNECTION PIECE	86323173C CONNECTION PIECE	$129.85	1	TO
009	WHT002219	SEAL RING IN	WHT002219 SEAL RING IN	$6.20	1	IN
010	86323209K	CLUTCH HOUSING	86323209K CLUTCH HOUSING	$3,204.39	1	TO
011	WHT003027	STUD BOLT M8X35	WHT003027 STUD BOLT M8X35	$9.10	11	TO
012	WHT002942	STUD BOLT	WHT002942 STUD BOLT	$10.82	3	TO
013	WHT003213	WASHER	WHT003213 WASHER	$1.29 MSRP: ~~7.15~~ (82% off)	3	TO
014	N1100637	NUT M6	N1100637 NUT M6	-	2	PE	문의하기
017	7M105269	Balanced Mechanism Clutch IN	7M105269 Balanced Mechanism Clutch IN	$7,766.30	1	IN
018	WHT003078	DOWEL	WHT003078 DOWEL	$16.89	1	TO
019	410141179	Plate IN	410141179 Plate IN	$65.93	4	IN
020	WHT002951	Screw M8X1,25X23 (Manual) IN	WHT002951 Screw M8X1,25X23 (Manual) IN	$20.95	8	IN
021	WHT002944	STUD BOLT M8X50	WHT002944 STUD BOLT M8X50	$16.46	2	TO
022	WHT003166	STUD BOLT M8X40	WHT003166 STUD BOLT M8X40	$49.77	1	TO
023	86141671L	Thrust Bearing IN	86141671L Thrust Bearing Valid for E-Gear IN	$2,125.34	1	IN
024	WHT002218	Seal Ring IN	WHT002218 Seal Ring IN	$1.03 MSRP: ~~7.30~~ (85.9% off)	1	IN
025	86141131	SEAL RING IN	86141131 SEAL RING IN	$22.49	1	IN
026	86311819	SEAL RING IN	86311819 SEAL RING IN	$56.87	1	IN
027	WHT003580	SEAL RING IN	WHT003580 SEAL RING IN	$16.84	1	IN
028	410911085A	BRACKET	410911085A BRACKET	$26.61	1	TO
029	86323179A	HYDRAULIC CLUTCH PIPE	86323179A HYDRAULIC CLUTCH PIPE	$224.46	1	TO
030	191611715	HOSE BRACKET	191611715 HOSE BRACKET	$1.98 MSRP: ~~7.14~~ (72.3% off)	1	TO
033	86325274A	CONNECTOR	86325274A CONNECTOR	$1,799.84	1	TO
034	86141305	SUPPORT IN	86141305 SUPPORT IN	$57.48	1	IN
035	86141297	Clutch Sensor IN	86141297 Clutch Sensor IN	$502.28	1	IN
036	N10421101	PIN IN	N10421101 PIN IN	$0.55 MSRP: ~~7.35~~ (92.5% off)	2	IN
037	N10295402	SCREW M5X20 IN	N10295402 SCREW M5X20 IN	$3.43 MSRP: ~~7.09~~ (51.6% off)	2	IN
038	N90659905	SCREW	N90659905 SCREW	$12.46	2	TO
039	410972846	SUPPORT	410972846 SUPPORT	$1.71 MSRP: ~~7.12~~ (76% off)	2	TO
040	86323131A	BRACKET	86323131A BRACKET	$57.05	1	TO
041	N91065401	SCREW M8X14 IN	N91065401 SCREW M8X14 IN	$2.80 MSRP: ~~7.22~~ (61.2% off)	2	IN
043	N10124306	OVAL HEXAGON SOCKET HEAD BOLT IN	N10124306 OVAL HEXAGON SOCKET HEAD BOLT IN	$2.67	3	IN
044	86323961	PLUG	86323961 PLUG	$48.42	1	TO
045	N160276	PLUG	N160276 PLUG	-	1	PE	문의하기
046	N138302	WASHER	N138302 WASHER	-	1	PE	문의하기
047	N138494	WASHER	N138494 WASHER	-	1	PE	문의하기
