Clutch Control Levers of Lamborghini Lamborghini Diablo (1990-1998)

Lamborghini Diablo (1990-1998) - Clutch Control Levers

부품 분해도를 보고 원하는 부품을 찾으세요.:

다이어그램을 드래그하여 위치를 변경할 수 있습니다.
다이어그램을 스크롤하거나 핀치하거나 and buttons

부품 다이어그램에서 핫스팟 클릭하여 표에서 부품을 찾을 수 있습니다.

부품 키

재고 있음

곧 도착

주문하기

문의하세요

다이어그램 탭하여 확대

0 부품 ($0.00)

경고: 항목에 대해 동일한 부품의 여러 이형 상품을 선택할 수 있습니다:

	#	부품 번호	부품 설명	부품 세부 정보	가격 (각)	수량 다이어그램	키	에 추가 장바구니
	001	4219984	CLUTCH PUMP	4219984 CLUTCH PUMP POMPA FRIZIONE	$348.89	1	TO
	N0152785		WASHER	from $0.72
002 WASHER $0.72 2 TO 028 WASHER $0.72 1 TO
	003	8100830	SCREW	8100830 SCREW VITE	$0.40 MSRP: ~~7.31~~ (94.5% off)	2	TO
	8200811		NUT	from $5.75 MSRP: ~~6.00~~ (4.2% off)
004 NUT $5.75 MSRP: ~~6.00~~ (4.2% off) 1 TO 034 NUT $5.75 MSRP: ~~6.00~~ (4.2% off) 1 TO
	005	8200809	NUT	8200809 NUT DADO	$1.98	1	TO
	WHT002962		WASHER 14X8.4X1.5	from $0.58 MSRP: ~~7.35~~ (92.1% off)
006 WASHER 14X8.4X1.5 IN $0.58 MSRP: ~~7.35~~ (92.1% off) 1 IN 009 WASHER 14X8.4X1.5 IN $0.58 MSRP: ~~7.35~~ (92.1% off) 1 IN 027 WASHER 14X8.4X1.5 IN $0.58 MSRP: ~~7.35~~ (92.1% off) 1 IN
	007	4219591	FORK	4219591 FORK FORCELLA	-	1	PE	문의하기
	008	8400819	WASHER 8X12X1	8400819 WASHER 8X12X1 RONDELLA	$0.60 MSRP: ~~7.29~~ (91.8% off)	1	TO
	010	2129460	JOURNAL	2129460 JOURNAL PERNO	$32.04 MSRP: ~~32.70~~ (2% off)	1	TO
	011	8900503	PIN - SPINA	8900503 PIN - SPINA SA	$1.00	2	TO
	012	N0122094	WASHER IN	N0122094 WASHER RONDELLA IN	$2.58 MSRP: ~~7.15~~ (63.9% off)	1	IN
	8100841		SCREW	from $108.84
013 SCREW $108.84 1 TO 024 SCREW $108.84 1 TO
	014	2125925	SHAFT	2125925 SHAFT ALBERO	$486.05	1	TO
	015	8900802	PIN - SPINA	8900802 PIN - SPINA SA	$7.45	2	TO
	N01100845		NUT M8X1,25X6,5	from $3.28
016 NUT M8X1,25X6,5 IN $3.28 11 IN 029 NUT M8X1,25X6,5 IN $3.28 1 IN
	017	WHT001514	WASHER IN	WHT001514 WASHER RONDELLA IN	$56.92 MSRP: ~~64.00~~ (11.1% off)	11	IN
	018	8300808	STUD BOLT	8300808 STUD BOLT use : WHT003027	$6.17	9	TO
	019	8522204	ROLLER CAGE	8522204 ROLLER CAGE GABBIAARULLI	$19.82 MSRP: ~~20.90~~ (5.2% off)	3	TO
	020	8576601	RETAINER RING	8576601 RETAINER RING ANELLO RITEGNO	$0.66 MSRP: ~~7.26~~ (90.9% off)	2	TO
	021	8605600	SEAL	8605600 SEAL ANELLO TENUTA	$44.78	1	TO
	022	2424858	COVER	2424858 COVER COPERCHIO	$139.43	1	TO
	023	2130853	PIPE	2130853 PIPE TUBO	$235.22	1	TO
	025	4225225	COUPLING	4225225 COUPLING TESTA A SNODO	-	1	PE	문의하기
	026	2129457	LEVER	2129457 LEVER LEVA	$544.24	1	TO
	030	2131194	CONNECTION	2131194 CONNECTION RACCORDO	$136.83	1	TO
	031	8583701	RETAINER RING	8583701 RETAINER RING ANELLO RITEGNO	$0.97 MSRP: ~~7.31~~ (86.7% off)	1	TO
	032	2129128	SPACER	2129128 SPACER DISTANZIALE	$60.68	2	TO
	033	2121672	FORK	2121672 FORK FORCELLA	$99.42	1	TO
	035	8850806	DOWEL	8850806 DOWEL GRANO	-	1	PE	문의하기
	036	2121345	ROD	2121345 ROD PUNTALE	$307.53	1	TO
	037	2131528	PIPE	2131528 PIPE TUBO	$153.75	1	TO
	038	2136948	PUMP CYLINDER 도착	2136948 PUMP CYLINDER CILINDRO POMPA 도착	$140.27	1	AS
	039	2110618	PIPE	2110618 PIPE TUBO	$82.10	1	TO
