Air Filters of Lamborghini Lamborghini Diablo SV (1995-1997)

Lamborghini Diablo SV (1995-1997) - Air Filters

부품 분해도를 보고 원하는 부품을 찾으세요.:

다이어그램을 드래그하여 위치를 변경할 수 있습니다.
다이어그램을 스크롤하거나 핀치하거나 and buttons

부품 다이어그램에서 핫스팟 클릭하여 표에서 부품을 찾을 수 있습니다.

부품 키

IN

재고 있음

AS

곧 도착

TO

주문하기

PE

문의하세요

Air Filters of Lamborghini Lamborghini Diablo SV (1995-1997)

다이어그램 탭하여 확대

0 부품 ($0.00)

경고: 항목에 대해 동일한 부품의 여러 이형 상품을 선택할 수 있습니다:

	#	부품 번호	부품 설명	부품 세부 정보		가격 (각)	수량 다이어그램	주문하기 주문 수량			키	에 추가 장바구니
	001	8832003	CLAMP IN	8832003 CLAMP FASCETTA IN		$45.94	8				IN
	002	7M919529	Air Temperature Sensor IN	7M919529 Air Temperature Sensor IN		$297.72	2				IN
	003	1330524	LEFT PIPE	1330524 LEFT PIPE TUBO SINISTRO		$206.75	1				TO
	003	1330525	RIGHT PIPE	1330525 RIGHT PIPE TUBO DESTRO		$135.83	1				TO
	004	2021139	VALVE	2021139 VALVE VALVOLA ARIA ADDIZIONALE		$4,644.24	2				TO
	005	1330454	PIPE	1330454 PIPE TUBO		$139.43 MSRP: ~~147.50~~ (5.5% off)	2				TO
	006	N01118312	HEXAGON NUT, SELF-LOCKING IN	N01118312 HEXAGON NUT, SELF-LOCKING DADO IN		$2.59	6				IN
	007	WHT002961	WASHER IN	WHT002961 WASHER RONDELLA IN		$0.64	6				IN
	008	7M919529A	PRESSURE SENSOR	7M919529A PRESSURE SENSOR SENSORE PRESSIONE ASSOLUTA		$458.88	2				TO
	009	8838701	STRAP	8838701 STRAP FASCETTA		$9.03	8				TO
	010	1334382	PIPE	1334382 PIPE TUBO SINISTRO		$97.60	1				TO
	010	1334383	PIPE	1334383 PIPE TUBO DESTRO		$92.89	1				TO
	011	1331286	RIGHT FLEX. HOSE	1331286 RIGHT FLEX. HOSE TUBO FLESSIBILE DESTRO		$113.24 MSRP: ~~115.50~~ (2% off)	1				TO
	011	1333774	LEFT FLEX. HOSE 도착	1333774 LEFT FLEX. HOSE TUBO FLESSIBILE SINISTRO 도착		$281.48	1				AS
	012	8700671	SCREW	8700671 SCREW VITE		$4.19	8				TO
	013	N91115501	Washer 6.2X22X1 IN	N91115501 Washer 6.2X22X1 RONDELLA IN		$1.88 MSRP: ~~7.33~~ (74.4% off)	8				IN
	014	1335516	RIGHT CASE	1335516 RIGHT CASE SCATOLA FILTRO ARIA DESTRO		$667.37	1				TO
	014	1335520	LEFT CASE	1335520 LEFT CASE SCATOLA FILTRO ARIA SINISTRO		$1,339.32	1				TO
	7M133843		FILTERING CARTRDIGE	from $28.31
015 Filtering Cartrdige IN $28.31 2 IN 015 Filtering Cartrdige IN $28.31 2 IN
	016	9411508	ELASTIC SUPPORT	9411508 ELASTIC SUPPORT SUPPORTO ELASTICO		$31.33	6				TO
	017	1337438	PIPE	1337438 PIPE TUBO FLESSIBILE		$387.68	2				TO
	N10718801		HEX COLLARED BOLT	from $1.67
018 HEX COLLARED BOLT $1.67 4 TO 021 HEX COLLARED BOLT $1.67 4 TO
	019	9453169	LEFT BRACKET	9453169 LEFT BRACKET STAFFA SX		$58.86	1				TO
	019	9453168	RIGHT BRACKET	9453168 RIGHT BRACKET STAFFA DX		$58.86	1				TO
	020	9453172	BRACKET	9453172 BRACKET STAFFA		$8.81	2				TO
	022	9453162	GASKET	9453162 GASKET GUARNIZIONE		$31.28	2				TO
	023	9453171	LEFT SUPPORT	9453171 LEFT SUPPORT SUPPORTO SX		$262.56	1				TO
	023	9453170	RIGHT SUPPORT	9453170 RIGHT SUPPORT SUPPORTO DX		$262.56	1				TO
